10G OEO Fiber Media Converter Card with SFP+ to XFP for 16 Slots Rack

Home Products 16 Slots Manageable Chassis

10G OEO Fiber Media Converter Card with SFP+ to XFP for 16 Slots Rack

Product Details:

Place of Origin:	China
Brand Name:	Fiberroad
Certification:	CE
Model Number:	FR-OEO-10GSX

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Please send inquiry to jojo@fiberroad.com.cn
Packaging Details:	White box
Delivery Time:	5-7days
Payment Terms:	T/T in advance
Supply Ability:	1000PCS/MONTH

Contact Now

Detailed Product Description

10G OEO Fiber Media Converter Card with SFP+ to XFP for 16 Slots Rack

16 Slots Manageable Chassis with In-Band managed Media Converter Rack system

The Model FR6000 Series is a Centralized Network management platform that provides 16 slots multi-service including Managed Media Converter Card, OEO Converter Card, 1+1 protection switching card,CWDM/DWDM MUX/DEMUX Card, etc.
All interface cards, fans, management module Card and AC/DC Reduntant Power Supply are hot swappable, allowing online field replacement.
Management can be achieved locally or Remote Standalone over the network by Web,SNMP,Telnet or Console. FR-6000 series together with the MUX and DEMUX offer a solution for CWDM/DWDM transmission that is space-efficient and cost-effective.

10G 3R SFP+ to XFP OEO Converter Card for Management Multi-service Platform

Key Features:

Supporting SFP+ to SFP+, SFP+ to XFP, XFP to XFP
Supporting 10Gbase-SR/LR/ER/ZR/LRM to 10Gbase-SR/LR/ER/ZR/LRM
Supporting 10Gbase LAN(10.3125 Gbps) and WAN(9.95328 Gbps)
3R function, stable data transmission
Short delay time when transparent transmission
Supporting Jumbo frame
Supporting DMI(Diagnostic Monitoring Interface) function of optical transceivers
Supporting 850nm, 1310nm, 1550nm and DWDM/CWDM wavelength ruled by ITUT
Supporting PRBS31 Pattern Generator and Checker and Loopback test, precisely locating the failure, convenient for link test
Economical management function within bandwidth
With powerful network management function, supporting WEB and SNMP
Supporting hot plug
Supporting Remote management
Easy installation with complete LED indicators for working situation
Supporting 2U chassis (16 slots) and standalone use

Specifications:

Interface

Port A

SFP+

XFP

Port B

SFP+

XFP

Transmission Speed

10G

Data

Technical Indexes

Function

3R Repeater

Protocols

IEEE802.3ae (10Gbase-SR/LR/ER/ZR/LRM)

Access Type

10G LAN/ 10G WAN

Transmission Distance

SFP+ module: Up to 80Km
XFP module: Up to 80Km

Maximum Packet

Forwarding Rate

14,880,950/S

Network management
information:

• Card type information
• SFP+ or XFP fiber module detection
• SFP+ or XFP fiber module DMI function

(Temperature Voltage ,Optical power )

• Link status detector
• Enable/Disabled Loopback test function
• Enable/Disable PRBS Generator and checker function
• Rate select (10Gbase-Lan or Wan )
• Remote card's status monitor (only in pairs )

Power requirement

Rack-mountable : AC 85 ~ 220V OR DC -48V
Standalone: AC 220V OR DC -48V
Power consumption: ≤6W

Work Environment

Operating Temp: 0~ 50 C
Storage Temp: -10~ 70 C
Humidity: 5%~90% (non-condensing )

Dimension

Card :11.5mm(W)×78mm(D)
Standalone :156mm(W)×128mm(D)×32mm(H)

Ordering Information:

P/N	Description	Remark
FR-6603-SS	10G OEO Converter Card (3R)	SFP+ TO SFP+
FR-6603R-SS	10G OEO Converter 3R (Remote Standalone)	SFP+ TO SFP+
FR-6603-SX	10G OEO Converter Card (3R)	SFP+ TO XFP
FR-6603R-SX	10G OEO Converter 3R (Remote Standalone)	SFP+ TO XFP
FR-6603-XX	10G OEO Converter Card (3R)	XFP TO XFP
FR-6603R-XX	10G OEO Converter 3R (Remote Standalone)	XFP TO XFP
